“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Lift Cylinder, Upper, 3772
ITEM PART NO. QTY DESCRIPTION
1 91315 1 Cylinder, Upper Lift, 3772RT
2 91377 1 Hose Assembly, Lift Cylinder 3/8" × 370"
3 HDW7601 1 Fitting, Elbow Adaptor
4 91805 1 Orifice, 0.067
5 90993 4 Bearing, Bronze, 2" ID × 2" LG
6 91462 1 Valve, 2 Way, N.C. Dual Coil
7–––
8 HDW6727 1 Fitting, Pipe 90°, Male Barb
9 HDW8152 2 Screw, ¼" - 20 × ¾" LG
10 – – –
11 16062 1 BRacket, Lift Cylinder Valve Guard
12 6458 40 FT Hose, 5/16", Return Line
13 – – –
14 7788 1 Clamp, Hose
15 90969 1 RELief Valve
16 91141 2 Coil, 12 Volt, Deutsch Connector w/Diode
– 90987 REF Kit, Seal-lift Cylinder (S ervice)
To Next Page
