“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Scissor Assembly, 3072RT: Serial #11211100 - UP (continued)
ITEM PART NO. QTY DESCRIPTION
11 13175 16 Washer, Nylon 2.062 ID × 2.620 OD × .030 THK
12 6701 12 Ring, Retaining, 2"
13 25429 12 Spacer Block - Beams
14 17012 2 CYLINDER MOUNT
15 14806 1 SUPPORT BEAM WELDMENT
16 14538 2 BRACKET, CYLINDER RETAINING
17 HDW6455 4 SCREW, ¼” - 20, ½” LG
18 14537 2 PIN, CYLINDER MOUNT
19 HDW8899 2 Retaining Clip
20 40459 2 LOWER PIVOT, MACHINED CASTING
21 HDW8457 6 LOCKNUT, ½” - 13, GR B
22 HDW6491 6 Washer, Flat, .562 ID × 1.375 OD × .109 THK
23 HDW8284 6 SCREW, ½” - 13, 2” LG, GR 8
24 5432 4 GREASE FITTING
25 6669 2 BEARING, 2” × 2”
26 90235 2 WEAR PAD, ANGLE, SLIDE BLOCK TOP
27 40306 2 SLIDE PVT, LWR CAST, MACHINED
8785 .67 FT TAPE, DOUBLE COATED
28 7160 2 BEARING, 1 ¾” × 2”
29 9587 2 WEAR PAD, SLIDE BLOCK, BOTTOM
30 HDW8303 8 SCREW, 5/16” - 18, 2” LG
31 HDW5217 8 WASHER, FLAT, .343 ID × .688 OD × .063 THK
32 HDW8294 8 WASHER, FLAT, .328 ID × 1.000 OD × .100 THK
33 HDW8304 8 NUT, 5/6” - 18
34 14487 2 BLOCK, SLIDE, PLATFORM
35 14488 2 BLOCK, SLIDE, PLATFORM
36 91020 1 Lift Cylinder
