"3072ES / 3772ES / 3772ES HD" Service & Parts Manual October 2008
Page 2-7
Battery Charger
Electrical Requirements
The use of an improper extension cord could result in a risk of fire or electric
shock.
The use of long extension cords should be minimized. If an extension cord is used, ensure that it has
three conductors with a ground and that the wire size and length meet electrical code for the voltages
and currents of the Electrical Specifications table. Locate all cords so that they will not be driven over,
stepped on, tripped over, or otherwise subjected to damage or stress.
Refer to the
Operator’s Manual
for detailed charging instructions.
Refer to
Section 4 - Troubleshooting.
Refer to
BATTERIES
earlier in this section.
Electrical Specifications Table - Battery Charger
MODEL
Voltage
Maximum Current
Frequency
Phase
HB750-24 (2 CHARGERS)
115 V (85-132 V)
230 V (170-264 V)
(automatically selects)
9.5 A at 85 V
4.8 A at 170 V
60 / 50 Hz
Single
HB1500-48
100 V (85-137 V)
240 V (170-264 V)
(automatically selects)
16 A at 96 V AC
8 A at 170 V AC
50 / 60 Hz
Single
AC InputDC Output
Voltage
Maximum Current
Output Power
29.6 V DC
25.0 A DC
750 Watts
61 V DC
25.0 A DC
1500 Watts
