October 2008
Page F-5
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Ballast (Counterweight) Installation
ITEM PART NO. QTY DESCRIPTION
1 40159 1 Base Weldment
2 HDW8457 8 Nut, Lock, ½”-13, GR 5
3 HDW13195 8 Washer, Flat, .515 ID × 1.512 OD × .098 THK
4 40590 1 Bar, Ballast Weight
5 16736 2 Bar, Counterweight Retainer
6 HDW90951 4 Screw, ½”-13, 6” LG, GR 5
7 HDW7018 4 Screw, ½”-13, 3” LG, GR 5
8
16368 1 Plate, Ballast Weight 3072RT
16368 2 Plate, Ballast Weight 3772RT
9 HDW13195 4 Washer, Flat
