Mec 3072ES - Hydraulic Hoses - Outrigger (HD Models

October 2008
Page E-17
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Hydraulic Hoses - Outrigger (HD Models)
ITEM PART NO. QTY DESCRIPTION
32 91346 4 Hose Assy, ¼"×35" (4G1-4FJX-4FJX90 S)
33 91347 4 Hose Assy, ¼"×58" (4G1-4FJX-4FJX90 S)
34 HDW7391 2 Tee, Male 3/8" jic
35 HDW9557 4 Tee, Male ¼" JIC
36 9038 2 Hose Assy, 3/8"×46" (6M3K-6FJX-6FJX)
37 91047 4 Hose Assy, ¼"×63" (4G1-4FJX-6FJX)
38 7598 1 Hose Assy, 3/8"×28" (6M3K-6FJX-6FJX)
39 8318 1 Hose Assy 3/8"×24" (6M3K-6FJX-6FJX90)
