“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
ART_2710
3072 Lift Cylinder
Rod Wiper
Rod
Rod Seal
Static Seal
Seal Retainer
Seal Kit
Piston
Wear Ring
Piston Seal
Wear Ring
Barrel
Wear Ring
3
4
5
5
5
5
6
7
16
15
8
9
11
12
14
1
2
91020 LIFT CYLINDER WITH BEARINGS
TO LIFT
MANIFOLD
TO RESERVOIR
