Mec 3072ES - Scissor Assembly, 3772 RT: Serial #11211100 - up

October 2008
Page C-11
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Scissor Assembly, 3772RT: Serial #11211100 - UP
… continued
ITEM PART NO. QTY DESCRIPTION
1 17019 1 Beam Weldment, 6x6x.188
2 17017 1 Beam Weldment, 6x6x.250
3 17015 1 Beam Weldment, 6x6x.188
4 16292 1 Beam Weldment, 6x6x.375
5 17011 1 Beam Weldment, 6x6x.375
6 17018 1 Beam Weldment, 6x6x.188
7 16288 1 Beam Weldment, 6x6x.250
