October 2008
Page D-9
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Wheel Motor, Front
ITEM PART NO. QTY DESCRIPTION
– 7300P – MOTOR WHEEL HYD PAINTED
1 90592 – SEAL KIT
1a – 1 DUST SEAL
1b – 1 HIGH PRESSURE SEAL
1c – 1 METAL BACKUP SHIM
1d – 1 TEFLON BACK UP SEAL
1e – 1 SHAFT SEAL
1f – 1 HOUSING SEAL
1g – 3 BODY SEALS
1h – 1 MANIFOLD SEAL
1i – 1 COMMUTATOR SEAL
1j – 1 O-RING SEAL
1k – 1 TEFLON BACKUP SEAL
