October 2008
Page C-13
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Scissor Assembly, 3772RT: Serial #11211100 - UP (continued)
2
ITEM PART NO. QTY DESCRIPTION
13 HDW13175 21 Washer, 2.062 ID × 2.620 OD × .030 THK
14 6701 17 Ring, Retaining, 2" Shaft
15 25429 16 Spacer Block - Beams
16 – – –
17 17012 4 CYLINDER MOUNT
18 16282 2 SUPPORT BEAM WELDMENT w/Bearings
19 14538 4 BRACKET, CYLINDER RETAINING
20 HDW6455 8 SCREW, ¼” - 20, ½” LG
21 14537 4 PIN, CYLINDER MOUNT
22 HDW8899 4 Retaining Clip
23 40459 2 LOWER PIVOT, MACHINED CASTING
24 HDW8457 6 LOCKNUT, ½” - 13, GR B
25 HDW6491 6 Washer, Flat, .562 ID × 1.375 OD × .109 THK
26 HDW8284 6 SCREW, ½” - 13, 2” LG, GR 8
27 5432 4 GREASE FITTING
28 6669 2 BEARING, 2” × 2”
29 90235 2 WEAR PAD, ANGLE, SLIDE BLOCK TOP
30
40306 2 SLIDE PVT, LWR CAST, MACHINED
8785 .67 FT TAPE, DOUBLE COATED
31 7160 2 BEARING, 1 ¾” × 2”
32 9587 2 WEAR PAD, SLIDE BLOCK, BOTTOM
33 HDW8303 8 SCREW, 5/16” - 18, 2” LG
34 HDW5217 8 WASHER, FLAT, .343 ID × .688 OD × .063 THK
35 HDW8294 8 WASHER, FLAT, .328 ID × 1.000 OD × .100 THK
36 HDW8304 8 NUT, 5/6” - 18
37 14487 2 BLOCK, SLIDE, PLATFORM
38 14488 2 BLOCK, SLIDE, PLATFORM
39 91315 1 Lift Cylinder, Upper
40 91314 1 Lift Cylinder, Lower
To Next Page
