October 2008
Page E-19
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Lift Cylinder, 3072
ITEM PART NO. QTY DESCRIPTION
1 91020 1 Cylinder, Lift 3072RT
2 90985 1 Hose Assembly, 3/8"
3 HDW7601 1 Fitting, Elbow Adaptor
4 91804 1 Orifice, 0.042
5 6669 4 Bearing, 2" ID × 2" LG
6 91051 1 Valve, 2 Way, N.C. Cable Attach
7 91141 1 Coil, 12 Volt, Deutsch
8 HDW6727 1 Fitting, Pipe 90°, Male Barb
9 HDW8152 2 SCREW, ¼" - 20 × ¾" LG
10 – – –
11 16062 1 Bracket, Lift Cylinder Valve Guard
12 6458 21 FT Hose, Return Line
13 – – –
14 7788 1 Clamp, Hose
15 91182 1 Cable, E-Down
16 HDW91240 1 Nut, Coupling 10-32 × ¾"
– 91460 REF Kit, Seal-Lift Cylinder (service)
