Mec 3072ES - Power to Platform - Airline to Platform

October 2008
Page B-15
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Power to Platform – Airline to Platform
ITEM PART NO. QTY DESCRIPTION
Power to Platform
1 90827 1 Box, Receptacle
2 90828 1 Duplex Receptacle Cover
3 HDW5636 1 Screw #6 - 32 × 0.25"
4 HDW6455 2 Screw, ¼" - 20, ½" LG
5 HDW8267 2 LOCKNUT ¼" - 20
6 5381 1 Receptacle, Duplex
7 8208 1 Conduit, 3/8" Flexible
8 8209 1 Ferrule, 3/8"
9 8479 1 Bushing, ¾" ID
10 8833 1 Connector, Outlet Box 3/8" Conduit
11 16221 1 Bracket
12 HDW5724 2 Screw, 5/16–18 × ¾"
13 HDW8304 2 Nut, 5/16–18
– HDW8501 2 Wire, 14 GA
–7617
50 FT 3072ES: Wire, 14 GA
58 FT 3772ES: Wire, 14 GA
HDW5217 2 Flat Washer 11/32" ID
Airline to Platform (not shown)
– 5351 1 Cable Tie
– 91399
49 FT 3072ES: Hose, 3/8" Airline
57 FT 3772ES: Hose, 3/8" Airline
– 8559 2 Clamp, Hose
– HDW91500 2 Fitting, ¼" Male, Male Hose Barb
– 5882 2 Cable Clamp
