October 2008
Page E-3
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Main Manifold Assembly
… continued
ITEM PART NO. QTY DESCRIPTION
– 91140 – Manifold Assembly
1 91141 4 Coil, Series 8, 12V
2 91142 1 Coil, Series 10, 12V
3–––
4 91144 1 Valve, Drive, 4 way 3 Position
5 91145 1 Valve, Lift Spool, 3 Way
6 91146 1 Valve, Steer, 4 Way 3 Position
7 91147 2 Valve, Series Parallel Spool, 4 way 3 position
8–––
9 91149 1 Valve, Relief, Lift
10 91150 1 Valve, relief, Steer
11 91151 3 Valve, Piloted Spool 4 way 3 position
12 91152 2 Valve, Piloted Poppet
13 91153 1 Valve, Load Shuttle Check
14 91154 2 Valve, Load Shuttle Check
15 91350 2 Valve, Counterbalance
16 91353 2 Valve, Check
17
HDW7314 2 Port plug M ¼", O-Ring, RBG-4
HDW7061 2 Adapter (w/ Outrigger Option)
18
7484 2 Port plug M 0.38" O-Ring, RBG-6
HDW7438 2 Adapter (w/ Outrigger Option)
19 91351 2 Flow Divider / Combiner
20 91355 1 Orifice Plug, Steer
21 91356 2 Orifice Plug, Flow Divider Bleed
22 91012 1 Valve, Manual — Pull
23 91354 1 Orifice Disc
24 91015 1 Hand Pump, Brake Release
25 91352 1 Pressure Compensator
26 HDW7314 2 Port plug M ¼", O-Ring, RBG-4
To Next Page
