Mec 3072ES - Swing Gate, CE Standard; ANSI Option

October 2008
Page B-11
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Swing Gate, CE Standard / ANSI Option
ITEM PART NO. QTY DESCRIPTION
1 40003 1 Latch Pin, Rear Gate
2 7055 1 Spring, Latch, .480 DIA. OD × 1.5" LG
3 40006 1 Rod, Latch Lever, Rear Gate
4 HDW6434 1 Screw, 3/8-16 × 2" LG
5 8187 2 Bearing, Nyliner, 5/8" ID × 5/8" LG
6 40014 1 Mounting Bracket, Upper
7 HDW8294 6 Washer, .328" ID × 1" OD × .100" THK
8 HDW8486 4 Screw, 5/16" - 18, 1 7/8" LG, GR 5
9 6823 1 Cap Plug, 1 ¼" Square
10 8300 1 Spring, Torsion, 1" DIA. OD × 4" LG
11 13272 1 Block, Pivot, Rear Gate
12 40015 1 Mounting Bracket, Lower
13 40017 1 Swing Gate Weldment
14 30814 1 Strike Plate
15 HDW8303 2 Screw, 5/6"-18, 2" LG, GR 5
16 HDW7120 2 Nut, 5/16"-18, GR 5
17 HDW8268 1 Nut, 3/8-16
