October 2008
Page E-9
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Manifold - Outrigger (HD Models)
ITEM PART NO. QTY DESCRIPTION
1 91721 1 Manifold Assembly
2 HDW7601 3 Elbow 90° Male 3/8" O-ring - Male 3/8" JIC
3 HDW8881 1 Adapter Male ¼" O-ring - Male ¼" JIC
4 91142 2 Coil
5 91720 1 Valve Spool 4-way 3-position
6 HDW7314 1 Port Plug
