Mec 3072ES - Main Manifold Assembly (Continued

October 2008
Page E-5
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Main Manifold Assembly (continued)
ITEM PART NO. QTY DESCRIPTION
28 HDW91248 3 Elbow, 90°, Male, ½", O-Ring, Male, ½", MB-MJ90LL-8-8
29 HDW90764 5 Elbow, 90°, Male, ½", O-Ring, Male, ½", MB-MJ90-8-8
30 HDW91334 1 Fitting, Orifice 1/16"
31 HDW8877 1 ELBOW, 90°, Male ¼” O-ring, Male ¼”, MB-MJ90-4-4
32 HDW91081 1 ELBOW, 90°, Male ¼” O-ring, Male ¼”, MB-MJ90LL-4-4
33 HDW91244 1 ELBOW, 90°, Male ¾” O-ring, Male ¾”, MB-MJ90-12-12
34 HDW91245 1 ELBOW, 90°, Male ¾” O-ring, Male ¾”,MB-MJ90LL-12-12
35 HDW9157 1 Elbow, 90°, Male .37 JIC, Male .37 O-RING, MB-MJ90LL-6-6
36 HDW7971 1 Fitting, Male Disconnect, ¼" NPT
37 HDW91243 1 adapter Male ¼" O-ring Male ¼" NTP, MP-MB-4-4
38 HDW8881 1 Adapter, Male ¼”, O-ring, Male ¼” 37° MB-MJ-4-4
