October 2008
Page C-1
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
S
ECTION
C
S
CISSORS
CONTENTS PAGE
Scissor Assembly, 3072RT: Up to Serial #11211099 . . . . . . . . . . . . . . . . . . . . C-3
Scissor Assembly, 3772RT: Up to Serial #11211099 . . . . . . . . . . . . . . . . . . . . C-5
Scissor Assembly, 3072RT: Serial #11211100 - UP . . . . . . . . . . . . . . . . . . . . . C-7
Scissor Assembly, 3072RT: Serial #11211100 - UP (continued) . . . . . . . . . . . C-9
Scissor Assembly, 3772RT: Serial #11211100 - UP . . . . . . . . . . . . . . . . . . . . C-11
Scissor Assembly, 3772RT: Serial #11211100 - UP (continued) . . . . . . . . . . C-13
Limit Switch Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-15
Scissor Guards - 3072ES, CE Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-17
Scissor Guards - 3772ES, CE Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-19
