Mec 3072ES - Page 206

October 2008
Page E-22
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
ART_2712
3772 Upper Lift Cylinder
91315 LIFT CYLINDER WITH BEARINGS
3
4
5
5
5
5
6
16
8
9
11
15
12
14
1
2
TO LIFT
MANIFOLD
TO RESERVOIR
Rod Wiper
Rod
Rod Seal
Seal Retainer
Seal Kit
Piston
Barrel
Wear Ring
