“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Outrigger Cylinder
ITEM PART NO. QTY DESCRIPTION
1 91278 4 Cylinder, Outrigger
2 91281 1 Switch, Outrigger Pressure N.O.
3–––
4 10907 1 Washer Actuator
5 HDW8476 1 Nut Jam ¼-20
6 HDW9761 1 Screw, Socket Head ¼-20 × 2½
7 91277 1 Switch, Outrigger Retract Limit N.O.
8 91464 2 Valve N.C. Poppet
9 91141 2 Coil 12V Deutsch
10 HDW91465 2 Adapter 3/8 Male O-Ring, ¼ Male JIC
11 90439 1 Orifice
– 91463 REF S eal Kit
