October 2008
Page F-3
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Base Assembly
ITEM PART NO. QTY DESCRIPTION
1 40159 1 Base Weldment
2
16160 1 Ladder Weldment, 3072RT Standard
16293 Ladder Weldment, 3772RT Standard
3 16206 1 Cover, Slider Pan
4 14993 2 Support, Module
5 HDW8283 16 Screw, ½" - 13, 1 ½" LG. GR8
6 HDW8531 4 Washer, .531 ID × 1.0 OD × .063 THK
7 HDW8457 16 Nut, ½" - 13, GR 5
8 HDW5723 12 Screw, ¼–12 × ¾"
9 HDW8267 12 Nut, ¼-20
