Mec 3072ES - Page 219

October 2008
Page F-7
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Modules Installation
ITEM PART NO. QTY DESCRIPTION
1
16985 1 Door Weldment, Control Module
16984 1 Door Weldment, Power Module (Not Shown)
2 8386 4 Latch Trigger
3 84077 1 Weldment, Power Module
4
16165 1 Cover, Hose Tray, LH 3072RT
16313 1 Cover, Hose Tray, LH 3772RT
5 16153 1 Weldment, Control Module
6 16164 1 Cover, Hose RH
7 HDW5723 8 Bolt, ¼”-20, ¾” LG, GR 5
8 HDW5417 8 Screw, 3/8”-16, 1.25” LG, GR 8
9 HDW5355 8 Washer, .438 ID × 1.000 OD × .078 THK
10 HDW8267 8 Nut, ¼-20
