October 2008
Page F-9
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Control Module
… continued
ITEM PART NO. QTY DESCRIPTION
1 ref – Control Module Weldment
2 83050 1 Control Panel
3 16154 1 Bracket, Cross Support
4 14896 4 Block, Slide, Door
5 25429 2 Pad
6 16226 1 Bracket, Control Panel
7 90749 1 Plug, Power to Platform
8 91748 1 Fitting, 1 1/8–¾ Male JIC
9 HDW9200 1 Plug, ¼ NPT
10 9367 1 Filler/Strainer
11 16229 1 Bracket, Battery Disconnect
12 8841 1 Switch, Battery Disconnect
13 91659 1 System Controller, GP400
14 91658 1 Motor Controller
15 91709 1 Fuse, 300 AMP
16 91745 1 Contactor, Solenoid 48V, 12V Coil
17 9370 1 Level Gauge
18 91140 1 Hydraulic Manifold
19 91721 1 Outrigger Manifold (HD Models)
20 91640 1 Electric Motor
21 8267 2 Nut, ¼–20
22 6727 3 Fitting
23 6714 1 Filter Head
24 HDW9268 1 Elbow, 90° ¾ NPT – ¾ JIC
25 6156 1 Filter Cartridge
26 HDW5724 4 Screw, 5/16–18 × ¾, GR5
27 HDW8273 4 Screw, ¼–20 × 1
28 HDW5217 4 Washer, .343ID × .680OD × .063THK
29 HDW8267 4 Nut, ¼–20, GR5
30 HDW8482 6 Bolt, 32 × 1.57
To Next Page
