“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
ART_2747
Decals3072ES - 3772ES - 3772ES HD
HYDRAULIC OIL
6873
Please see service manual for additional information.
100% charged
75% to 100% charged
50% to 75% charged
0 to 50% charged
ON
ON
ON
50%
Blinking
ON
ON
Blinking
OFF
ON
Blinking
OFF
OFF
75% 100%
BATTERY CHARGER
INDICATOR
90826
REFER TO MAINTENANCE MANUAL FOR
REPLACEMENT PART NUMBER.
8519
REPLACE TIRES WITH MANUFACTURER'S
EQUIPMENT ONLY.
FAILURE TO USE MANUFACTURER'S
TIRES MAY CAUSE MACHINE INSTABILITY.
WARNING
DANGER
STAND CLEAR
OUTRIGGER CONTACT
WILL CAUSE SERIOUS
CRUSHING INJURY
9465
91389
90732
DO NOT POWERWASH OR
SPRAY ELECTRONIC
COMPONENTS OR
CONNECTORS.
MOISTURE MAY CAUSE
DAMAGE AND/OR
ERRATIC OPERATION
WARNING
7156
LOCATE CONTROL BOX HERE
FOR NORMAL OPERATION OF THIS UNIT
7155
DRIVE
ENABLED
HOLD SWITCH IN
DESIRED DIRECTION
AUTOMATIC
OUTRIGGERS
RETRACT
EXTEND
91349
ANSI Models: Sheet 2 of 4
RAISE
LOWER
PLATFORM
BASE
PUSH FOR EMERGENCY
STOP
TWIST TO RESET
MEC AERIAL PLATFORM SALES CORP.
1775 PARK STREET, SUITE 77
SELMA, CA 93662, USA
MFG DATE
XX/XX
MAX. PLATFORM CAPACITY INCLUDING PERSONS
XXX LBS
XXX kg
MAX. SIDE LOAD
XXX LBS
XXX N
MAX. DRIVE HEIGHT
XX FT
X.X m
MAX. PLATFORM HEIGHT
XX FT
X.X m
THIS MACHINE HAS BEEN CONSTRUCTED IN ACCORDANCE WITH SECTION 4 OF ANSI A92.6 COVERED BY US PAT. #5,476,050 & CANADIAN PAT. # 2,115,870
MAX. GROUND
PRESSURE PER WHEEL
XX PSI
XXX kg/cm²
MAX. LOAD
PER WHEEL
XXX LBS
XXX kg
MAX. HYDRAULIC
SYSTEM
PRESSURE
XXXX PSI
XXX bar
STANDARD
MACHINE WEIGHT
XXXX LBS
XXX kg
OPTIONAL EQUIPMENT ADDS
TO STANDARD MACHINE WEIGHT
FOAM FILLED TIRES = XXX LBS, XXX kg
LEVELING OUTRIGGERS = XXX LBS, XXX kg
= X PERSONS + EQUIPMENT
= X PERSONS + EQUIPMENT
XXXXXX XXXXXXXX 20XX
MODEL NUMBER
(THESE TWO NUMBERS INCLUDE ALL POSSIBLE OPTIONS)
SERIAL NUMBER
MODEL
YEAR
90651
91374
EMERGENCY LOWERING
SWITCH INSIDE
8502
INFLATE TO TIRE
MANUFACTURER'S MAX.
SPECIFICATIONS
SERVICE MANUAL
OR SEE
91083
26
30
33
41
40
44
47
48
45
46
39
42
43
38
36
37
34
35
31
32
27
28
29
NOTE: Decal placement is subject to the original country of the equipment destination.
