“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
ART_2750
Decals3072ES - 3772ES - 3772ES HD
MEC 3772ES HD
MEC 3072ES
CERTIFIED LANYARD
8605
ANCHORAGE POINT
9910
11026730
TIP-OVER HAZARDS
YOU MUST NOT OPERATE
THIS MACHINE:
DO NOT DRIVE NEAR DROP-OFFS, HOLES
OPEN ELEVATOR SHAFTS, AND LOADING DOCKS
DO NOT ELEVATE PLATFORM ON
UNEVEN OR SOFT SURFACES
DO NOT DRIVE ONTO UNEVEN OR
SOFT SURFACES WHEN ELEVATED
DO NOT RAISE PLATFORM ON SLOPE, OR DRIVE
ONTO SLOPE WHEN ELEVATED
DO NOT RAISE PLATFORM IN
WINDY OR GUSTY CONDITIONS
DEATH OR SERIOUS INJURY
WILL RESULT FROM IMPROPER
USE OF THIS EQUIPMENT
DEATH OR SERIOUS INJURY
WILL RESULT FROM CONTACT
OR INADEQUATE CLEARANCE
90721
ELECTROCUTION HAZARD
THIS MACHINE IS NOT INSULATED
UNLESS YOU HAVE BEEN AUTHORIZED TO
USE AND TRAINED IN THE SAFE OPERATION
OF THIS MACHINE.
TRAINING INCLUDES COMPLETE KNOWLEDGE OF
THE SAFETY AND OPERATION INSTRUCTIONS
CONTAINED IN THE MANUFACTURERS MANUAL,
ANSI MANUAL OF RESPONSIBILITIES, YOUR
EMPLOYERS WORK RULES AND APPLICABLE
GOVERNMENTAL REGULATIONS.
AN UNAUTHORIZED AND UNTRAINED OPERATOR
SUBJECTS THEMSELF AND OTHERS TO
DEATH OR SERIOUS INJURY.
MAINTAIN SAFE CLEARANCE FROM ELECTRICAL
LINES AND APARATUS. YOU MUST ALLOW FOR
MACHINE SWAY, ROCK OR SAG AND ELECTRICAL
LINES SWAYING.
THIS MACHINE DOES NOT PROVIDE PROTECTION
FROM CONTACT WITH OR PROXIMITY TO AN
ELECTRICALLY CHARGED CONDUCTOR.
YOU MUST MAINTAIN A CLEARANCE OF AT
LEAST TEN (10) FEET BETWEEN ANY PART
OF THIS MACHINE OR ITS LOAD AND ANY
ELECTRICAL LINE OR APARATUS CARRYING UP
TO 50,000 VOLTS. ONE FOOT OF ADDITIONAL
CLEARANCE IS REQUIRED FOR EVERY
ADDITIONAL 30,000 VOLTS OR LESS.
INSPECT MACHINE AND MAKE SURE THAT IT IS OPERATING PROPERLY,
THAT ALL NAME PLATE AND SAFETY AND CONTROL DECALS ARE IN PLACE
AND LEGIBLE, AND THAT THE MACHINE IS IN ACCORDANCE WITH THE
MANUFACTURER'S MAINTENANCE REQUIREMENTS CONTAINED IN THE
OPERATION AND MAINTENANCE MANUAL AND THE DAILY SAFETY CHECKLIST.
OPERATE MACHINE WITH EXTREME CAUTION. WATCH FOR OBSTRUCTIONS
WHICH MAY STRIKE PLATFORM, PERSONNEL, CONTROLS, OR MACHINE.
OPERATE CONTROLS SLOWLY FOR SMOOTH PLATFORM MOTION.
FOR DRIV ING ON A NY GRADE OR SIDE SLO PE:
FOR DRIV ING W ITH PLATFORM ELEVATED :
PLATFO RM MUST BE FULLY LOW ERED.
DRIVE ONLY O N A SMOOTH , FI RM, AN D LEVEL
SURFAC E FREE OF OBSTRU CTIONS.
DO NOT EXCEED MAXIMUM PLATFO RM O R
EXTENSIO N LO AD L IMIT CAPACITY.
LOAD TO BE UNIFORMLY DI STRI BUTE D.
PLACE LOA D NEAR CENTER OF PLATFORM
WHEN POSSI BLE.
DO NOT DRIVE ON SIDE SLOPE IF OV ER 2 5% (14°).
DO NOT DRIVE UP OR DOWN A GRADE THAT IS
GREATE R TH AN THE GRADEABILITY
SPECIFIC AT IONS F OR T HIS MACH INE.
SEE OPER ATOR MANUAL FOR SPECIFICATIO NS.
DO NOT EXCEED MAXIMUM PLATFO RM O R
EXTENSIO N LO AD C APACITY.
LOAD MUST BE UNIFORMLY DISTR IBUT ED.
USE EXTR EME CAUTION.
OTHER HAZARDS
IMPROPER OPERATION OF THIS MACHINE
COULD CAUSE DEATH OR SERIOUS INJURY.
1. DO NOT OVE RLOA D PL ATFORM LOA D CAPACITY.
2.
DO NOT EXCEED MAXIMUM SIDE FORCE AND
MAXIMUM NUMBER OF OCCUPANT S.
3.
DO NOT USE WI THOU T GUAR D RA ILS IN PLACE ,
AND ENTRY GATE PRO PERLY SECURED.
4.
DO NOT USE IF WORK PLATFO RM IS NOT WOR KING
PROPERLY OR IF ANY PART IS DA MAGE D OR WORN.
5. DO NOT USE NEAR MOV ING V EHICLES OR CRANES.
6.
DO NOT STAND OR SIT ON GUA RDRA ILS,
ALL PERSON NEL S HA LL ALWAYS MAINTAIN FIRM
FOOTI NG ON PLATF ORM FLOOR.
7.
DO NOT USE WH ILE UNDER TH E IN FLUENCE OF
ALCOHOL OR D RUGS.
8. DO NOT OVERRIDE SAFETY DEVICES.
9.
DO NOT LEAVE MAC HINE UNATTE NDED WIT H KE Y
IN TH E SW ITCH.
10.
DO NOT RAISE PLATF ORM WHILE MAC HINE I S O N
A T RUCK , FO RKLI FT, O R OT HER DEVICE OR
VEHICLE.
11.
DO NOT USE LADDER, SCAFFOLDING, OR OT HER
DEVICES TO INCREASE SIZ E OR WORKING H EIGH T
OF PLATF ORM.
12.
DO NOT ENTER OR EXIT PLATF ORM WHILE IN
MOT ION.
13.
DO NOT RECHAR GE BATT ERIE S N EAR
SPAR KS
OR OPEN FLAME, BATT ERIE S E MIT
HIGHLY E XPLO SIVE HYDRO GEN GAS.
14.
DO NOT PERFOR M SERV ICE ON T HE M ACHI NE
WITHOUT PROP ERLY B LOCKING ELEVATIN G
ASSEMBLY.
15.
DO NOT ATTACH OVE RHAN GING LOA DS OR
NICREA SE P LATFORM SIZ E.
91456
90730
FAILURE TO FOLLOW INSTRUCTIONS COULD CAUSE
DEATH, PERSONAL INJURY AND PROPERTY DAMAGE
WARNING
SHEET LOADING GATE MUST BE IN LOWERED LOCKED
POSITION BEFORE OPERATING FROM PLATFORM.
PLATFORM ENTRANCE MUST BE PROPERLY CLOSED AND
ALL GUARDRAILS PROPERLY IN PLACEAND SECURED
BEFORE OPERATING FROM PLATFORM.
PLATFORM EXTENSION MUST BE LOCKED IN PLACE AT ALL
TIMES.
WARNING
90726
EACH REPLACEMENT BATTERY MUST WEIGH
A MINIMUM OF 60 POUNDS / 27.3 kg
FAILURE TO MEET MINIMUM WEIGHT
REQUIREMENT MAY CAUSE MACHINE
INSTABILITY.
8911
CE Models: Sheet 1 of 4
7
10
18
15
16
21
22
17
23
24
1
6
2
5
4
3
19
20
91385
454 kg
487 kg 261 kg
33 kg
273 kg 181 kg
400N
454 kg
214 kg 181 kg 33 kg
273 kg 181 kg
400N
11
91384
340 kg
180 kg 147 kg
33 kg
159 kg 181 kg
400N
340 kg
180 kg 147 kg 33 kg
159 kg 181 kg
400N
12
8 9
NOTE: Decal placement is subject to the original country of the equipment destination.
