Mec 3072ES - Page 47

"3072ES / 3772ES / 3772ES HD" Service & Parts Manual October 2008
Page 2-9
ART_2373
DO NOT CHANGE THE INPUT V
0306070098
BEFORE “ALL THE LEDS TURN OFF”
HB750-24
HB750-24
Please see service manual for additional information.
100% charged
75% to 100% charged
50% to 75% charged
0 to 50% charged
ON
ON
ON
50%
Blinking
ON
ON
Blinking
OFF
ON
Blinking
OFF
OFF
75% 100%
BATTERY CHARGER
INDICATOR
90826
LEDs
Dual Chargers
Early models are equipped with two 750 watt 24 Volts DC battery chargers working in-line to provide
48 Volts DC to the battery pack.
ART_2374
HB1500-48
ALL LED’S MUST BE OFF BEFORE
CONNECTING TO AC POWER
INDUSTRIAL
BATTERY CHARGER
FAU LTSTATUS
HSB1500-48
AUTO SELECTABLE DUAL AC INPUT
100 - 240V ~ 50/60 Hz 18A
48V
25A
Please see service manual for additional information.
Normal, battery is 100% charged
Normal, battery is over 80% charged
Normal operation, charger is charging
No AC power to charger
OFF
ON
ON
YELLOW
OFF
OFF
ON
OFF
OFF
ON
OFF
OFF
OFF
80% 100% FAULT
BATTERY CHARGER
INDICATOR
OFF
OFF
OFF
OFF
STATUS
80% 100%
FAULT
Single Chargers
Current models are equipped with a single 1500 Watt 48 Volts DC battery charger.
