"3072ES / 3772ES / 3772ES HD" Service & Parts Manual October 2008
Page 4-9
UP MAX
60%
5C-2
Identification Number
Personality
Default Setting
- match with information tables
- does not appear on EZ-Cal display
ART_2722
Using the EZ-Cal with the Flow Charts
Use the EZ-cal Flow Charts on page 4-10 through page 4-13 as a guide to locate diagnostic informa-
tion and make adjustments. Each box in the flow chart will have 3 bits of information.
The IDENTIFIER (5c2):
Used to locate this specific personality in the informational charts. Here you
can obtain specific information on the individual personalities.
The PERSONALITY (Up Max):
Identifies the individual personalities.
The DEFAULT SETTING:
The factory setting. If adjustments are made, they must be returned to
default setting.
Changing Settings
It is necessary to enter Access Level 1 in order to change settings.
Error Messages
Refer to
HELP Menu
on page 4-21.
Scrolling Messages
The EZ-Cal will provide a scrolling message of the current error followed by a log of previous errors
that may have occurred within recent operation. Refer to
Scrolling Message
on page 4-21.
Flash Codes
Flash Codes, provided from the GP400 red LED, will also assist in the event an EZ-cal is not available
however; the EZ-cal yields considerably more relevant information. Refer to
EZ-Cal HELP MES-
SAGES
beginning on page 4-25
For flash codes.
Access Level 1
Access Level 1 is restricted.
If Setup or Personality changes are necessary, contact the factory to
obtain instructions and authorization to make changes to factory settings (publication number 91777).
Access Level 1 is required for Setup and Personality changes. Only qualified service personnel
should be allowed to make adjustments in these areas.
PERSONALITIES ARE PRESET AT THE FACTORY TO PROVIDE PROPER MACHINE
MOVEMENT AT SAFE SPEEDS. PERSONALITIES MUST NOT BE CHANGED
WITHOUT PRIOR AUTHORIZATION FROM MEC AERIAL AND MAY ONLY BE
RETURNED TO FACTORY SPECIFICATION.
