MEDIATEK Ralink MT7620 - List of Registers

PGMT7620_V.1.0_040503
Page 108 of 523
MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
2.10.4 List of Registers
No.
Offset
Register Name
Description
Page
120
0x0010
CTRL0
Control 0
109
121
0x0014
TRANS_CFG
Transfer Configuration
109
122
0x0018
CMD1
Command 1
110
123
0x001C
CMD2
Command 2
110
124
0x0020
CMD3
Command 3
111
125
0x0024
ADDR
Address
111
126
0x0028
DATA
Data
111
127
0x0030
STATUS
ECC Status
111
128
0x0034
INT_ENA
Interrupt Enable
112
129
0x0038
INT_STA
Interrupt Status
112
130
0x003C
CTRL1
Control 1
112
131
0x0040
ECC_PAGE1
Error Correction Code Page 1
113
132
0x0044
ECC_PAGE2
Error Correction Code Page 2
113
133
0x0048
ECC_PAGE3
Error Correction Code Page 3
113
134
0x004C
ECC_PAGE4
Error Correction Code Page 4
113
135
0x0050
ECC_ERR_PAGE1
ECC Error Information Page 1
113
136
0x0054
ECC_ERR_PAGE2
ECC Error Information Page 2
114
137
0x0058
ECC_ERR_PAGE2
ECC Error Information Page 3
114
138
0x005C
ECC_ERR_PAGE3
ECC Error Information Page 4
114
139
0x0060
ADDR2
Address 2
115
