MEDIATEK Ralink MT7620 - List of Registers

PGMT7620_V.1.0_040503
Page 98 of 523
MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
2.9.3 List of Registers
No.
Offset
Register Name
Description
Page
111
0x0000
CONFIG
I
2
C Configuration
99
112
0x0004
CLKDIV
I
2
C Clock Divisor
99
113
0x0008
DEVADDR
I
2
C Device Address
100
114
0x000C
ADDR
I
2
C Address
100
115
0x0010
DATAOUT
I
2
C Data Out
100
116
0x0014
DATAIN
I
2
C Data In
101
117
0x0018
STATUS
I
2
C Status
101
118
0x001C
STARTXFR
I
2
C Transfer Start
102
119
0x0020
BYTECNT
I
2
C Byte Counter
102
