MEDIATEK Ralink MT7620 - List of Registers

PGMT7620_V.1.0_040503
Page 162 of 523
MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
2.15.6 List of Registers
No.
Offset
Register Name
Description
Page
200
0x0000
SDRAM_CFG0
SDRAM Configuration 0
163
201
0x0004
SDRAM_CFG1
SDRAM Configuration 1
163
202
0x0008
TCH_ARB_CFG
Two Channel Arbiter Configuration
165
203
0x0010
ILL_ACC_ADDR
Illegal Access Address Capture
165
204
0x0014
ILL_ACC_TYPE
Illegal Access Type Capture
165
205
0x0018
DDR_SELF_REFRESH
DDR Self Refresh
166
206
0x001C
SDR_DDR_PWR_SAVE_CNT
SDR DDR Power Save Counter
167
207
0x0020
to 0024
Reserved
-
168
208
0x0040
DDR_CFG0
DDR Configuration 0
168
209
0x0044
DDR_CFG1
DDR Configuration 1
169
210
0x0048
DDR_CFG2
DDR Configuration 2
171
211
0x004C
DDR_CFG3
DDR Configuration 3
173
212
0x0050
DDR_CFG4
DDR Configuration 4
174
213
0x0054
to 005C
Reserved
-
174
214
0x0060
DDR_CFG8
DDR Configuration 8
175
215
0x0064
DDR_CFG9
DDR Configuration 9
175
216
0x0068
DDR_CFG10
DDR Configuration 10
175
217
0x006C
DDR_CFG11
DDR Configuration 11
176
