MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
Offset
Type
Name
Description
Initial Value
3:1
RW
RX_PKEY_MODE
Pairwise Key Security Mode
0: No security
1: WEP40
2: WEP104
3: TKIP
4: AES-CCMP
5: CKIP40
6: CKIP104
7: CKIP128
*
0
RW
RX_PKEY_EN
Key Table Selection
0: Shared key table
1: Pairwise key table
*
Table 3-3 WCID Attribute Entry Format
3.1.4 Shared Key Mode Entry Format (1DW)
Bits
Type
Name
Description
Initial Value
31:28
RW
SKEY_MODE_7+
Shared key7+(8x) mode, x=0 to 3
*
27:24
RW
SKEY_MODE_6+
Shared key6+(8x) mode, x=0 to 3
*
23:20
RW
SKEY_MODE_5+
Shared key5+(8x) mode, x=0 to 3
*
19:16
RW
SKEY_MODE_4+
Shared key4+(8x) mode, x=0 to 3
*
15:12
RW
SKEY_MODE_3+
Shared key3+(8x) mode, x=0 to 3
*
11:8
RW
SKEY_MODE_2+
Shared key2+(8x) mode, x=0 to 3
*
7:4
RW
SKEY_MODE_1+
Shared key1+(8x) mode, x=0 to 3
*
3:0
RW
SKEY_MODE_0+
Shared key0+(8x) mode, x=0 to 3
*
Table 3-4 Shared Key Mode Entry Format (1DW)
Key mode definition:
0: No security
1: WEP40
2: WEP104
3: TKIP
4: AES-CCMP
5: CKIP40
6: CKIP104
7: CKIP128
8: WAPI
9 to 15: Reserved
