MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
Offset
Type
Name
Description
Initial Value
0x7780
RW
SKEY_60
Shared key for BSS_IDX=15, KEY_IDX=0
*
0x77A0
RW
SKEY_61
Shared key for BSS_IDX=15, KEY_IDX=1
*
0x77C0
RW
SKEY_62
Shared key for BSS_IDX=15, KEY_IDX=2
*
0x77E0
RW
SKEY_63
Shared key for BSS_IDX=15, KEY_IDX=3
*
Table 3-11 Shared Key Table Extension (for BSS_IDX=8 to15) (offset: 0x7400)
3.3.9 WAPI PN Table (Extension of IV/EIV Table) (offset: 0x7800)
Offset
Type
Name
Description
Initial Value
0x7800
RW
WAPI_PN_MSB_0
Extension byte11 to byte8 of WAPI PN for WCID0
*
0x7804
RW
WAPI_PN_MSB_0
Extension byte15 to byte12 of WAPI PN for WCID0
*
0x7808
RW
WAPI_PN_MSB_1
Extension byte11 to byte8 of WAPI PN for WCID1
*
0x780C
RW
WAPI_PN_MSB_1
Extension byte15 to byte12 of WAPI PN for WCID1
*
….
RW
….
Extension byte11 to byte8 of WAPI PN for WCID2
to WCID254
*
….
RW
….
Extension byte15 to byte12 of WAPI PN for WCID2
to WCID254
*
0x7FF8
RW
WAPI_PN_MSB_255
Extension byte11 to byte8 of WAPI PN for
WCID255
*
0x7FFC
RW
WAPI_PN_MSB_255
Extension byte15 to byte12 of WAPI PN for
WCID255
*
Table 3-12 WAPI PN Table (Extension of IV/EIV Table) (offset: 0x73F0)
NOTE: Do not set WIV bit to 1 when WAPI mode is turned on.
