MEDIATEK Ralink MT7620 - List of Registers

PGMT7620_V.1.0_040503
Page 140 of 523
MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
2.13.3 List of Registers
No.
Offset
Register Name
Description
Page
170
0x0000
SPISTAT0171
SPI Interface 0 Status
141
171
0x0004
Reserved
-
141
172
0x0008
Reserved
-
141
173
0x000C
Reserved
-
141
174
0x0010
SPICFG0
SPI Interface 0 Configuration
141
175
0x0014
SPICTL0
SPI Interface 0 Control
142
176
0x0020
SPIDATA0
SPI Interface 0 Data
143
177
0x0024
SPIADDR0
SPI Interface 0 Address
144
178
0x0028
SPIBS0
SPI Interface 0 Block Size
144
179
0x002C
SPIUSER0
SPI Interface 0 User Mode
144
180
0x0030
SPITXFIFO0
SPI Interface 0 TX_FIFO
146
181
0x0034
SPIRXFIFO0
SPI Interface 0 RX_FIFO
146
182
0x0038
SPIFIFOSTAT0
SPI Interface 0 FIFO_STATUS
146
183
0x003C
SPIMD0
SPI Interface 0 Mode
147
184
0x0040
SPISTAT1
SPI Interface 1 Status
147
185
0x0050
SPICFG1
SPI Interface 1 Configuration
147
186
0x0054
SPICTL1
SPI Interface 1 Control
148
187
0x0060
SPIDATA1
SPI Interface 1 Data
149
188
0x0080
SPIDMA
SPI Interface DMA
150
189
0x0084
SPIDMASTAT
SPI Interface DMA_FIFO_STATUS
150
190
0x00F0
SPIARB
SPI Interface Arbiter
150
