MEDIATEK Ralink MT7620 - Peripheral Channel Connection

PGMT7620_V.1.0_040503
Page 133 of 523
MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
2.12.3 Peripheral Channel Connection
Channel number
Peripheral
0
Reserved
1
ND Controller
2
I2S Controller (TXDMA)
3
I2S Controller (RXDMA)
4
PCM Controller (RDMA, channel-0)
5
PCM Controller (RDMA, channel-1)
6
PCM Controller (TDMA, channel-0)
7
PCM Controller (TDMA, channel-1)
8
PCM Controller (RDMA, channel-2)
9
PCM Controller (RDMA, channel-3)
10
PCM Controller (TDMA, channel-2)
11
PCM Controller (TDMA, channel-3)
12
SPI Controller (RXDMA)
13
SPI Controller (TXDMA)
8 to 15
Reserved
