MEDIATEK Ralink MT7620 - List of Registers

PGMT7620_V.1.0_040503
Page 63 of 523
MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
2.6.3 List of Registers
No.
Offset
Register Name
Description
Page
46
0x0000
RBR
Receive Buffer Register
64
47
0x0004
TBR
Transmit Buffer Register
64
48
0x0008
IER
Interrupt Enable Register
64
49
0x000C
IIR
Interrupt Identification Register
65
50
0x0010
FCR
FIFO Control Register
66
51
0x0014
LCRLCR
Line Control Register
66
52
0x0018
MCR
Modem Control Register
67
53
0x001C
LSR
Line Status Register
68
54
0x0020
MSR
Modem Status Register
69
55
0x0024
SCRATCH
Scratch
70
56
0x0028
DL
Clock Divider Divisor Latch
70
57
0x002C
DLLO
Clock Divider Divisor Latch Low
71
58
0x0030
DLHI
Clock Divider Divisor Latch High
71
