MEDIATEK Ralink MT7620 - Table 3-8 Shared Key Table; Table 3-9 Shared Key Mode

PGMT7620_V.1.0_040503
Page 478 of 523
MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
Offset
Type
Name
Description
Initial Value
0x6D60
RW
SKEY_11
Shared key for BSS_IDX=2, KEY_IDX=3
*
0x6D80
RW
SKEY_12
Shared key for BSS_IDX=3, KEY_IDX=0
*
0x6DA0
RW
SKEY_13
Shared key for BSS_IDX=3, KEY_IDX=1
*
0x6DC0
RW
SKEY_14
Shared key for BSS_IDX=3, KEY_IDX=2
*
0x6DE0
RW
SKEY_15
Shared key for BSS_IDX=3, KEY_IDX=3
*
0x6E00
RW
SKEY_16
Shared key for BSS_IDX=4, KEY_IDX=0
*
0x6E20
RW
SKEY_17
Shared key for BSS_IDX=4, KEY_IDX=1
*
0x6E40
RW
SKEY_18
Shared key for BSS_IDX=4, KEY_IDX=2
*
0x6E60
RW
SKEY_19
Shared key for BSS_IDX=4, KEY_IDX=3
*
0x6E80
RW
SKEY_20
Shared key for BSS_IDX=5, KEY_IDX=0
*
0x6EA0
RW
SKEY_21
Shared key for BSS_IDX=5, KEY_IDX=1
*
0x6EC0
RW
SKEY_22
Shared key for BSS_IDX=5, KEY_IDX=2
*
0x6EE0
RW
SKEY_23
Shared key for BSS_IDX=5, KEY_IDX=3
*
0x6F00
RW
SKEY_24
Shared key for BSS_IDX=6, KEY_IDX=0
*
0x6F20
RW
SKEY_25
Shared key for BSS_IDX=6, KEY_IDX=1
*
0x6F40
RW
SKEY_26
Shared key for BSS_IDX=6, KEY_IDX=2
*
0x6F60
RW
SKEY_27
Shared key for BSS_IDX=6, KEY_IDX=3
*
0x6F80
RW
SKEY_28
Shared key for BSS_IDX=7, KEY_IDX=0
*
0x6FA0
RW
SKEY_29
Shared key for BSS_IDX=7, KEY_IDX=1
*
0x6FC0
RW
SKEY_30
Shared key for BSS_IDX=7, KEY_IDX=2
*
0x6FE0
RW
SKEY_31
Shared key for BSS_IDX=7, KEY_IDX=3
*
Table 3-8 Shared Key Table (offset: 0x6C00)
3.3.5 Shared Key Mode (offset: 0x7000)
Offset
Type
Name
Description
Initial Value
0x7000
RW
SKEY_MODE_0_7
Shared mode for SKEY0 to SKEY7
*
0x7004
RW
SKEY_MODE_8_15
Shared mode for SKEY8 to SKEY15
*
0x7008
RW
SKEY_MODE_16_23
Shared mode forSKEY16 to SKEY23
*
0x700C
RW
SKEY_MODE_24_31
Shared mode for SKEY24 to SKEY31
*
Table 3-9 Shared Key Mode (offset: 0x7000)
3.3.6 Spare Memory Space Mode (offset: 0x7010 to 0x73EC)
