MEDIATEK Ralink MT7620 - Table 3-5 Pairwise Key Table

PGMT7620_V.1.0_040503
Page 477 of 523
MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
3.3.1 Pairwise Key Table (offset: 0x4000)
Offset
Type
Name
Description
Initial Value
0x4000
RW
PKEY_0
Pairwise key for WCID0
*
0x4020
RW
PKEY_1
Pairwise key for WCID1
*
….
RW
….
Pairwise key for WCID2 to 253
*
0x5FC0
RW
PKEY_254
Pairwise key for WCID254
*
0x5FE0
RW
PKEY_255
Pairwise key for WCID255 (not used)
*
Table 3-5 Pairwise Key Table (offset: 0x4000)
3.3.2 IV/EIV Table (offset: 0x6000)
Offset
Type
Name
Description
Initial Value
0x6000
RW
IVEIV_0
IV/EIV for WCID0
*
0x6008
RW
IVEIV_1
IV/EIV for WCID1
*
….
RW
….
IV/EIV for WCID2 to WCID253
*
0x67F0
RW
IVEIV_254
IV/EIV for WCID254
*
0x67F8
RW
IVEIV_255
IV/EIV for WCID255 (not used)
*
Table 3-6 IV/EIV Table (offset: 0x6000)
3.3.3 WCID Attribute Table (offset: 0x6800)
Offset
Type
Name
Description
Initial Value
0x6800
RW
WCID_ATTR_0
WCID attribute for WCID0
*
0x6804
RW
WCID_ATTR_1
WCID attribute for WCID1
*
….
RW
….
WCID attribute for WCID2 to WCID253
*
0x6BF8
RW
WCID_ATTR_254
WCID attribute for WCID254
*
0x6BFC
RW
WCID_ATTR_255
WCID attribute for WCID255
*
Table 3-7 WCID Attribute Table (offset: 0x6800)
3.3.4 Shared Key Table (offset: 0x6C00)
Offset
Type
Name
Description
Initial Value
0x6C00
RW
SKEY_0
Shared key for BSS_IDX=0, KEY_IDX=0
*
0x6C20
RW
SKEY_1
Shared key for BSS_IDX=0, KEY_IDX=1
*
0x6C40
RW
SKEY_2
Shared key for BSS_IDX=0, KEY_IDX=2
*
0x6C60
RW
SKEY_3
Shared key for BSS_IDX=0, KEY_IDX=3
*
0x6C80
RW
SKEY_4
Shared key for BSS_IDX=1, KEY_IDX=0
*
0x6CA0
RW
SKEY_5
Shared key for BSS_IDX=1, KEY_IDX=1
*
0x6CC0
RW
SKEY_6
Shared key for BSS_IDX=1, KEY_IDX=2
*
0x6CE0
RW
SKEY_7
Shared key for BSS_IDX=1, KEY_IDX=3
*
0x6D00
RW
SKEY_8
Shared key for BSS_IDX=2, KEY_IDX=0
*
0x6D20
RW
SKEY_9
Shared key for BSS_IDX=2, KEY_IDX=1
*
0x6D40
RW
SKEY_10
Shared key for BSS_IDX=2, KEY_IDX=2
*
