MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
Table 2-29: 0x1398 TX_RATE_LUT_EN = 1 and MULTI_MAC_ADDRESS = 1
Offset
Type
Name
Description
Initial Value
0x1800
RW
WC_ENTRY_0
WC MAC address with WCID=0
0x0
0x1808
RW
WC_ENTRY_1
WC MAC address with WCID=1
0x0
….
RW
….
WC MAC address with WCID=2 to 110
0x0
0x1B78
RW
WC_ENTRY_111
WC MAC address with WCID=111
0x0
0x1B80
RW
MULTI_MAC_ADDR0
Multiple MAC address 0
0x0
0x1B88
RW
MULTI_MAC_ADDR1
Multiple MAC address 1
0x0
….
RW
….
Multiple MAC address 2 to 14
0x0
0x1BF8
RW
MULTI_MAC_ADDR15
Multiple MAC address 15
0x0
0x1C00
RW
WCID0_TX_RATE
Bit{15:0}: WCID0 Tx Rate
0x0
0x1C08
RW
WCID1_TX_RATE
Bit[15:0]: WCID1 Tx Rate
0x0
….
RW
….
Bit[15:0]: WCID=2 to 126 Tx Rate
0x0
0x1FF8
RW
WCID127_TX_RATE
Bit[15:0]: WCID127 Tx Rate
0x0
