MEDIATEK Ralink MT7620 - List of Registers

PGMT7620_V.1.0_040503
Page 134 of 523
MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
2.12.4 List of Registers
No.
Offset
Register Name
Description
Page
160
0x0000, 0x0010, 0x0020,
0x0030, 0x0040, 0x0050,
0x0060, 0x0070, 0x0080,
0x0090, 0x00A0, 0x00B0,
0x00C0, 0x00D0, 0x00E0,
0x00F0
GDMA_SAn
GDMA Channel n Source Address
135
161
0x0004, 0x0014, 0x0024,
0x0034, 0x0044, 0x0054,
0x0064, 0x0074, 0x0084,
0x0094, 0x00A4, 0x00B4,
0x00C4, 0x00D4, 0x00E4,
0x00F4
GDMA_DAn
GDMA Channel n Destination Address
135
162
0x0008, 0x0018, 0x0028,
0x0038, 0x0048, 0x0058,
0x0068, 0x0078, 0x0088,
0x0098, 0x00A8, 0x00B8,
0x00C8, 0x00D8, 0x00E8,
0x00F8
GDMA_CT0n
GDMA Channel n Control 0
135
163
0x000C, 0x001C, 0x002C,
0x003C, 0x004C, 0x005C,
0x006C, 0x007C, 0x008C,
0x009C, 0x00AC, 0x00BC,
0x00CC, 0x00DC, 0x00EC,
0x00FC
GDMA_CT1n
GDMA Channel n Control 1
136
164
0x0200
GDMA_UNMASKINT
GDMA Unmasked Interrupt Status
137
165
0x0204
GDMA_DONEINT
GDMA Interrupt Status
138
166
0x0220
GDMA_GCT
GDMA Global Control
138
167
0x02A0
GDMA_REQSTS
GDMA Request Status
138
168
0x02A4
GDMA_ACKSTS
GDMA Acknowledge Status
138
169
0x02A8
GDMA_FINSTS
GDMA Finish Status
138
