MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
Bits
Type
Name
Description
Initial Value
0
RO
ECC_ERR
HW ECC Failed
0: Pass
1: Fail
0x0
139. ADDR2: Address 2 (offset: 0x0060)
Bits
Type
Name
Description
Initial Value
31:24
-
-
Reserved
0x0
23:16
RW
ADD_BYTE7
7th byte of NAND memory address
0x0
15:8
RW
ADD_BYTE6
6th byte of NAND memory address
0x0
7:0
RW
ADD_BYTE5
5th byte of NAND memory address
0x0
