MEDIATEK Ralink MT7620 - Page 254

PGMT7620_V.1.0_040503
Page 254 of 523
MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
2.20.7.2 Register Descriptions
288. MISC1: MISC I Register (offset: 0x0000)
Bits
Type
Name
Description
Initial Value
31:0
-
-
Reserved
0x0
289. PFC: PPE Forward Control Register (offset: 0x0004)
Bits
Type
Name
Description
Initial Value
31:4
-
-
Reserved
0x0
3
RW
PPE_EN
PPE Port Enable
1’b0: No PPE
1’b1: Enable PPE port
0x0
2:0
RW
PPE_PORT
PPE Port Number
Sets the PPE port number.
3’h0: Port 0
…
3’h7: Port 7
0x0
290. AISR: ACL Interrupt Status Register (offset: 0x0008)
Bits
Type
Name
Description
Initial Value
31:0
W1C
ACL_ISR
32 ACL Interrupt Status
(Refer to ACL_Rule_Control)
0x0
291. AGC: ARL Global Control Register (offset: 0x000C)
Bits
Type
Name
Description
Initial Value
31:19
-
-
Reserved
0x0
18
RO
ACL_INIT
Access Control List (ACL) Table Initialization
Done
1'b0: ACL Table is busy.
1'b1: ACL Table is cleared
0x1
17
RO
VLAN_INIT
VLAN Table Initialization Done
1'b0: VLAN Table is busy.
1'b1: VLAN Table is cleaned.
0x1
16
RO
ADDR_INIT
ADDR Table Initialization Done
1'b0: ADDR Table is busy.
1'b1: ADDR Table is cleaned.
0x1
15
RW
RATE_COMP
Rate Limit Compensation
Add or subtract the specific byte number while
calculating the packet length.
1'b0: Add
1'b1: Minus
0x0
14:8
RW
COMP_BNUM
Compensation Byte Number
The added/subtracted byte number for the rate
limit or the meter table.
0x18
