MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
2.20.8 BMU Registers
2.20.8.1 List of Registers
0x1000, 0x1100, 0x1200,
0x1300, 0x1400, 0x1500,
0x1600, 0x1700
Max-Min Scheduler Control Register 0 of
Queue 0/Port n
0x1004, 0x1104, 0x1204,
0x1304, 0x1404, 0x1504,
0x1604, 0x1704
Max-Min Scheduler Control Register 1 of
Queue 0/Port n
0x1008, 0x1108, 0x1208,
0x1308, 0x1408, 0x1508,
0x1608, 0x1708
Max-Min Scheduler Control Register 0 of
Queue 1/Port n
0x100C, 0x110C, 0x120C,
0x130C, 0x140C, 0x150C,
0x160C, 0x170C
Max-Min Scheduler Control Register 1 of
Queue 1/Port n
0x1010, 0x1110, 0x1210,
0x1310, 0x1410, 0x1510,
0x1610, 0x1710
Max-Min Scheduler Control Register 0 of
Queue 2/Port n
0x1014, 0x1114, 0x1214,
0x1314, 0x1414, 0x1514,
0x1614, 0x1714
Max-Min Scheduler Control Register 1 of
Queue 2/Port n
0x1018, 0x1118, 0x1218,
0x1318, 0x1418, 0x1518,
0x1618, 0x1718
Max-Min Scheduler Control Register 0 of
Queue 3/Port n
0x101C, 0x111C, 0x121C,
0x131C, 0x141C, 0x151C,
0x161C, 0x171C
Max-Min Scheduler Control Register 1 of
Queue 3/Port n
0x1020, 0x1120, 0x1220,
0x1320, 0x1420, 0x1520,
0x1620, 0x1720
Max-Min Scheduler Control Register 0 of
Queue 4/Port n
0x1024, 0x1124, 0x1224,
0x1324, 0x1424, 0x1524,
0x1624, 0x1724
Max-Min Scheduler Control Register 1 of
Queue 4/Port n
0x1028, 0x1128, 0x1228,
0x1328, 0x1428, 0x1528,
0x1628, 0x1728
Max-Min Scheduler Control Register 0 of
Queue 5/Port n
0x102C, 0x112C, 0x122C,
0x132C, 0x142C, 0x152C,
0x162C, 0x172C
Max-Min Scheduler Control Register 1 of
Queue 5/Port n
0x1030, 0x1130, 0x1230,
0x1330, 0x1430, 0x1530,
0x1630, 0x1730
Max-Min Scheduler Control Register 0 of
Queue 6/Port n
0x1034, 0x1134, 0x1234,
0x1334, 0x1434, 0x1534,
0x1634, 0x1734
Max-Min Scheduler Control Register 1 of
Queue 6/Port n
