MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
4.1.1 TXD Format
SDL0[13:0]
DDONE
LS0
SDL1[13:0]
BURST
LS1
SDP1[31:0]
QSEL
WIV
Reserved [4:0]
bit 31
bit 0
Reserved[23:0]
SDP0[31:0]
DWORD0 DWORD1 DWORD2 DWORD3
Figure 4-2 TXD Format
The following is a detailed description of each field in the TXD.
