The PIOEDGE bits have different meanings
depending on whether the interrupt for that
pin is enabled via the PIORMASK or PIOFMASK
register.
Read
If the PIO Pin Interrupt for this PIO pin is
asserted, the corresponding PIOEDGE bit
indicates whether a falling or rising edge
triggered the interrupt.
0: Interrupt triggered by falling edge.
1: Interrupt triggered by rising edge.
If the interrupt is masked (disabled), the
PIOEDGE bit is set on either a rising or falling
edge and remains set until cleared by firmware.
Bits corresponding to pins that are not set as
inputs will never be set.
Write
All bits are cleared by writing 1 to either this
register or the PIOINT register.
NOTE: Changes to the PIO pins can only be
detected when the clock is running.
83. GPIO39_24_RMASK: PIO Pin Rising Edge Interrupt Mask (offset: 0x0040)
PIO Pin Rising Edge Interrupt Mask
Masks the PIO interrupt indicating when data
on the corresponding PIO pin transitions from a
0 to a 1, i.e. a rising edge.
0: No mask
1: Mask
NOTE: Edge detection is done after the polarity
is adjusted according to the PIOPOL register.
84. GPIO39_ 24_FMASK: PIO Pin Falling Edge Interrupt Mask (offset: 0x0044)
PIO Pin Falling Edge Interrupt Mask
Masks the PIO interrupt indicating when data
on the corresponding PIO pin transitions from a
1 to a 0, i.e. a falling edge.
0: No mask
1: Mask
NOTE: Edge detection is done after the polarity
is adjusted according to the PIOPOL register.
