10 - 2 VM600 MPS hardware manual (standard version) MAMPS-HW/E
Edition 17 - February 2018
Definition of screw terminals on the IOC8T card
CONFIGURATION OF AMC8 / IOC8T CARDS
Connector J2: Connection of sensors 5 to 8
1
Channel 5 – Current Source
Output (I)
2 Channel 5 – Input (H)
3 Channel 5 – Input (R) 4 Channel 5 – Common Input (C)
5 Channel 5 – Shield (S) 6 Channel 5 – Chassis Ground
7
Channel 6 – Current Source
Output (I)
8 Channel 6 – Input (H)
9 Channel 6 – Input (R) 10 Channel 6 – Common Input (C)
11 Channel 6 – Shield (S) 12 Channel 6 – Chassis Ground
13
Channel 7 – Current Source
Output (I)
14 Channel 7 – Input (H)
15 Channel 7 – Input (R) 16 Channel 7 – Common Input (C)
17 Channel 7 – Shield (S) 18 Channel 7 – Chassis Ground
19
Channel 8 – Current Source
Output (I)
20 Channel 8 – Input (H)
21 Channel 8 – Input (R) 22 Channel 8 – Common Input (C)
23 Channel 8 – Shield (S) 24 Channel 8 – Chassis Ground
Connector J3: DC Outputs (DC OUT n) and DSI control inputs (AR and DB)
1
DC Output 1 (DC OUT 1) –
Signal
2
DC Output 1 (DC OUT 1) –
Return
3
DC Output 2 (DC OUT 2) –
Signal
4
DC Output 2 (DC OUT 2) –
Return
5
DC Output 3 (DC OUT 3) –
Signal
6
DC Output 3 (DC OUT 3) –
Return
7
DC Output 4 (DC OUT 4) –
Signal
8
DC Output 4 (DC OUT 4) –
Return
9
DC Output 5 (DC OUT 5) –
Signal
10
DC Output 5 (DC OUT 5) –
Return
11
DC Output 6 (DC OUT 6) –
Signal
12
DC Output 6 (DC OUT 6) –
Return
13
DC Output 7 (DC OUT 7) –
Signal
14
DC Output 7 (DC OUT 7) –
Return
15
DC Output 8 (DC OUT 8) –
Signal
16
DC Output 8 (DC OUT 8) –
Return
17 Alarm Reset (AR) – Input 18
Alarm Reset (AR) – Return
(0 V digital)
19 Danger Bypass (DB) – Input 20
Danger Bypass (DB) – Return
(0 V digital)
Table 10-1: Definition of terminals for connectors J1 to J4 on the IOC8T card (continued)
Terminal Definition Terminal Definition
To Next Page
