VM600 MPS hardware manual (standard version) MAMPS-HW/E 10 - 3
Edition 17 - February 2018
Definition of screw terminals on the IOC8T card
CONFIGURATION OF AMC8 / IOC8T CARDS
Connector J4: Relay contacts
1 Relay RL1 – NC contact (normally closed)
2 Relay RL1 – NO contact (normally open)
3 Relay RL1 – COM contact (common)
4 Relay RL2 – NC contact
5 Relay RL2 – NO contact
6 Relay RL2 – COM contact
7 Relay RL3 – NC contact
8 Relay RL3 – NO contact
9 Relay RL3 – COM contact
10 Relay RL4 – NC contact
11 Relay RL4 – NO contact
12 Relay RL4 – COM contact
Table 10-1: Definition of terminals for connectors J1 to J4 on the IOC8T card (continued)
Terminal Definition Terminal Definition
