76 Operating Instructions - CPC6050
Modular Pressure Controller
CPC6050
Burst_Detect YES,NO Sets burst detection enable, see Sec-
tion 6.4.3.10 Detection Flags.
Burst_Detect? <sp>(YES or NO)<cr><lf> Returns whether burst detection is
enabled or not
Burst_Chan A, B Sets the burst channel over the bus
and makes that channel the active
remote channel
Burst_Chan? <sp>(A or B)<cr><lf> Returns the active burst channel
Burst_Start Changes the screen to the Burst Test
if on another screen, begins the burst
test with current parameters.
Burst_Stop Stops the test and vents the system.
Burst_State? <sp>(IDLE or RUNNING or
COMPLETE)<cr><lf>
Returns state of the burst test
Burst_Low Value inside upper and lower limits This is the lower pressure of the an-
ticipated “burst range”
Burst_Low? <sp>n.nnnnnE+nn<cr><lf> Returns the lower pressure limit for
burst test
Burst_High Value inside upper and lower limits This is the higher pressure limit of the
anticipated “burst range”
Burst_High? <sp>n.nnnnnE+nn<cr><lf> Returns the higher pressure limit for
burst test
Burst_Slow Value inside upper and lower limits This is the rate used during the transi-
tion from low setpt to high setpt in the
anticipated “burst range”
Burst_Slow? <sp>n.nnnnnE+nn<cr><lf> Returns the slow rate for burst test
Burst_Fast Value inside upper and lower limits This is the rate used during the transi-
tion from atmosphere to the low setpt
Burst_Fast? <sp>n.nnnnnE+nn<cr><lf> Returns the fast rate for burst test
Burst_Result? <sp>n.nnnnnE+nn<cr><lf> Pressure at which burst was detected.
Will return 0 if no burst found.
Calculate_as_found_
linearity
Calculate linearity slopes and inter-
cepts from true/actual pressures
Caldisable YES,NO Sets whether or not calibration of the
active transducer is disabled.
Caldisable? <sp>(YES or NO)<cr><lf> Returns whether or not calibration of
the active transducer is disabled.
Calibration_mode? <sp>(YES or NO)<cr><lf> Returns the current calibration mode
setting
