Enter the block name.
1. Block activa-
tion
Block activation can be determined at the start of all block program-
ming.
Select from the following options in the display under Block activa-
tion:
– No
Program block not carried out
– Permanent
The program block is a permanent component of the program struc-
ture and is always carried out.
– Block+
The program block is only carried out when the + "Block+" button
has been pressed.
2. Program stop 1
Used to stop a current program.
Choose from the following options:
– No
No program stop occurs.
– Permanent
A program stop always occurs at the point programmed.
– Starch stop
– Spin stop
When "Starch stop" or "Spin stop" are selected, a program stop only
occurs at the point programmed if the relevant button is pressed at
that time.
– Spin and Starch stop
When "Starch stop" or "Spin stop" are selected, a program stop only
occurs at the point programmed if both the "Starch stop" and the
"Spin stop" buttons are pressed at that time.
3. Program stop
signal 1.
Used to set a "Program stop" output (for signal transmitter) for a pro-
gram stop.
Choose from the following options:
– No
The output "Program stop" is not activated for a program stop.
