Optional modules
44
Dispenser calibration
Dispenser calibration is used to measure the throughput of individual
dispenser pumps.
To go directly to
Dispenser calibra-
tion when the ma-
chine is switched
off:
Press and hold multifunction button 2 and turn the machine on with
the Power On button.
Options:
– Dispenser pump 1to13
Select a dispenser pump.
When a dispenser pump is selected, the following will appear in the
display:
Tip: The dispensing amount can be set from 0 to 9999 ml in 1 ml
steps.
Press multifunction button 0/1
The dispensing tube will fill up.
Press the0/1 button to stop the process.
Place the hose of the dispenser pump which is being checked at an
upward gradient in a measuring vessel.
Irritant detergents.
Irritant for skin and eyes
Avoid contact with skin and eyes, wear protective clothing.
Return to the main menu by pressing "Back".
