Optional modules
42
Liquid dispensing (optional for machines with detergent
compartment)
A
Dispenser pump
B
Siphon tube
a
Hose connection socket (suction side)
b
Hose connection socket (pressure side)
c
Outlet (in case of hose leakage)
d
Suction inlet opening
e
Display indicator level checker. When the dispenser is empty the
pump and the machine switch themselves off.
Continuing program after "Dispensing system fault"
message
If the dispensing container is empty the pump and the machine
switch off independently. At the same time the machine indicates a
lack of liquid detergent.
