Programming
159
Remove the card from the card reader.
Tip: The program is only deleted from the memory when the program
is finished and the card has been removed from the card reader.
If the programs on the card are not suitable for the model of machine,
the following message will appear:
Card contents
Card programs are only
applicable for machine type ??.
A card can hold max. 30programs each consisting of 6blocks. If
there is only one program on it, the Laundry load operation option is
carried out.
Information on
calling up card
content
Before the start or after the end of a program information can be
called up about card content.
Insert a card with data into the card reader and press the far-right
function button at the same time.
Information about card content will appear immediately.
Card contents
Program
PW 81x
14:09 25.3.2015
Content of a card with a program as shown in the display.
Tip: When the card is removed or the button is pressed the dis-
play returns to normal.
Locking cards
There is the option of locking and unlocking the card using the PC
software.
Tip: Data on the card cannot be changed when it is locked.
Insert the card into the card reader.
If there is a locked card in the reader, the following message will ap-
pear for 5seconds when the either menu option "Data to card" or
"Delete card" are selected and confirmed with the multifunction se-
lector:
Supervisor level
Main menu
A data modification is not possible.
Card is read only.
