Turn liquid dispensing off manually using the "Dispensing Off" func-
tion button.
After the program has started no detergent will be dispensed via the
dispenser pumps and the following message, e.g. will be displayed:
Dispensing quantities
Please follow the detergent manufacturer's instructions.
Risk of injury!
Violent chemical reactions and material damage.
Always follow the instructions of the chemical manufacturer when
using cleaning agents and special application chemicals. Only use
such chemicals for the purpose and in the situation specified by
the manufacturer in order to avoid the danger of adverse chemical
reactions and material damage.
Tip: Correct dosage also depends on the viscosity of the liquid deter-
gent. It should therefore be allowed to settle to room temperature be-
fore being used.
Connecting the dispenser pumps
Connection terminals for 4 time-controlled dispenser pumps, which
can be operated without a multifunction module, are located behind
the cover adjacent to the electrical connection. See the attached
wiring diagram.
Once the machine has been successfully installed and connected,
replace all the external parts that were removed.
Commissioning the dispenser pumps
Before the liquid dispenser pumps can be used the liquid detergent
must be drawn into the system and the amount to be dispensed set.
